Grinding machine is a kind of grinding and grinding workpiece mainly by grinding wheel, so that it can reach the required flatness. According to the shape of the table, it can be divided into rectangular table and circular table. The main parameter of the rectangular table curve grinding machine is the work table. Width and length, the main parameter of the rotary table grinding machine is the work surface diameter. According to the different types of shafts, it can be divided into horizontal shaft and vertical shaft grinding machine. For example, M7432 vertical shaft round table curve grinding machine, M7130 horizontal axis rectangular table curve grinding machine.
Curve Grinder Operation Instructions
1, curve grinder positioning
The machine tool should be reserved for more than 300mm outside the sports space. Each foot screw is tight, and the front and rear sides of the table are within 0.04/1000mm. (The requirements for installing the inverter need to be higher)
Check every three months, adjust the level of the work surface, and tighten each foot screw.
2, curve grinding wheel
The selected grinding wheel must be able to withstand a peripheral speed of 2000 m/min or more.
It is forbidden to use damaged wheels.
The new wheel must be balanced on the flange.
The grinding machine with a feed stroke of 800mm or less is 0.03mm, and the grinding machine with a diameter of 800mm or more is 0.05mm.
3, curve grinding machine spindle
Make sure the spindle rotates clockwise before installing the grinding wheel.
When starting up, you must first open the spindle and then flush it.
4. Curve grinding machine hydraulic device
The curve grinder uses a hydraulic fluid with a viscosity of 46.
The new machine needs to be replaced after three months of use, and then replaced once a year, and the tank must be cleaned.
Check the hydraulic oil level every day and the oil level should be between the low and high lines.
Before starting the hydraulic motor, make sure that the flow control lever (if configured) is in the off position.
Must first open the magnetic opening and then open the hydraulic pressure
5, curve grinding machine lubrication device
Lubricating oils use rail lubricants with a viscosity of 32-46.
Confirm the fuel tank (pool) oil volume every day to ensure that it is above the line.
Check the rail oil circuit for smoothness every week to prevent the rail from losing oil.
It is recommended to clean the tank every three months.
Grease is regularly refilled as specified.
